Type of vehicle – Shacman X9 Truck
Drive Type – 4X2
Tank Material – Stainless Steel
Overall dimension (mm) – 8,700x2,500x3,200
Type of vehicle – Shacman X9 Truck
Drive Type – 4X2
Tank Material – Stainless Steel
Overall dimension (mm) – 8,700x2,500x3,200
Road sweepers (also known as street sweepers, road cleaning vehicles, sweeping machinery, or municipal sweepers) play an indispensable role in modern urban sanitation. The Shacman X9 Sweeper Truck, launched by Shaanxi Automobile Group (SHACMAN), is specifically designed to meet the stringent cleaning needs of urban and industrial areas. With its superior reliability, high efficiency, and environmentally friendly characteristics, it is an ideal choice for maintaining the cleanliness of public spaces such as parking lots and streets.
The Shacman X9 Sweeper Truck combines powerful functions with advanced technology:
High-Efficiency Sweeping Capacity: Maximum sweeping width up to 3.5 meters, operating speed range 3-15 km/h, road sweeping speed up to 15-20 km/h, maximum sweeping area of up to 54,000 square meters per hour, sweeping efficiency ≥95%, ensuring rapid and thorough cleaning of large areas.
Powerful and Environmentally Friendly Engine: Equipped with a 180kW engine, meeting Euro 3 emission standards, balancing powerful performance with environmental requirements, the maximum speed reaches 89 km/h, ensuring efficient relocation and operation.
Superior Mobility and Passability: Adopting a 4×2 drive configuration, it offers flexible handling and easily adapts to complex urban environments such as parking lots and narrow alleys.
Convenient Unloading Design: A 45° garbage bin tilting angle significantly improves unloading efficiency and operational convenience.
Detailed Features: Large-Capacity Garbage Bin: The Shacman X9 Sweeper Truck is equipped with a 7-cubic-meter extra-large garbage bin, reducing the frequency of unloading and supporting long-term continuous operation, easily handling large amounts of garbage and waste.
Multi-functional Cleaning System: The vehicle has a built-in 9-cubic-meter water tank, effectively suppressing dust and achieving wet cleaning to create a dust-free environment. The water-dust combined design makes it suitable for various cleaning scenarios.
Power and Environmental Protection Combined: The 180kW Euro 3 engine provides reliable power while actively responding to the concept of sustainable development, meeting strict emission regulations, and contributing to the improvement of urban air quality.
All-round efficient operation From rapid transfer (up to 89 km/h) to fine sweeping (3-15 km/h) and then to road cleaning (15-20 km/h), Shacman X9 Sweeper Truck achieves full-process optimization, significantly improving the efficiency of cleaning work.
| SHACMAN X9 SWEEPER TRUCK | |
| Kerb Weight (Kg) | 11,940 |
| Garbage Tank Volume (m3) | 7 |
| Tank Material | Stainless Steel |
| Sweep Speed(km/h) | 3-15 |
| Max.Cleaning Width(m) | 3.5 |
| Tipper unloading angle(°) | 45 |
| Secondary engine Power(kW) | 125 |
| Overall Dimensions(LxWxH)(mm) | 8,700×2,500×3,200 |
| Water Tank Volume (m3) | 9 |
| Sweeper brush | 2 |
| Speed of Road Cleaning(km/h) | 15-20 |
| Max.Sweeping Capacity(m2/h) | 54,000 |
| Max. Suction size(mm) | 100 |
| Sweeping Efficiency (%) | 95 |
| [Chassis Technical Parameters] | |
| Brand Name | SHACMAN |
| Fuel Type | diesel |
| Front Axle/Rear Axle (t) | 7/12 |
| Number of Axles | 2 |
| Number of Tires | 6 |
| Brake | Air Brake/Oil Brake |
| Engine Power(kW) | 180 |
| Gearbox Model | 8-Speed Manual |
| Wheelbase(mm) | 5,000 |
| Tire Size | 10.00R20 |
