Model – SX4186NN361
Type of vehicle – Tractor Truck
Series – F3000
Power – 300hp
Engine – Weichai WP10.300E40
Maximum Speed(km/h) – 92
Overall dimension (mm) – 6150X2490X4000
Model – SX4186NN361
Type of vehicle – Tractor Truck
Series – F3000
Power – 300hp
Engine – Weichai WP10.300E40
Maximum Speed(km/h) – 92
Overall dimension (mm) – 6150X2490X4000
The Camion Shacman F3000 4×2 Tractor Truck is a globally proven heavy-duty workhorse in Shacman’s iconic F3000 series, engineered with German MAN-derived technology to deliver unbeatable reliability for medium and heavy hauling tasks worldwide. As one of Shacman’s longest-running best-selling models, it has earned a rock-solid reputation across Africa, the Middle East, Southeast Asia and Latin America for being “built to last, easy to maintain and low on operating costs”.
Every detail of the Camion Shacman F3000 4×2 tractor is optimized for harsh real-world operations. Its cab uses a full European high-strength frame that has passed the strict ECE-R29 crash test, offering full collision protection for drivers. The telescopic-shaft shift system absorbs all harsh vibration from the chassis, eliminating spontaneous gear disengagement on rough roads, while the fully sealed cab design blocks dust, noise and exhaust fumes from entering the cabin — a critical advantage for operations on unpaved construction sites and desert routes.
Under the hood, it runs on a field-proven Weichai four-valve diesel engine that puts out a steady 380hp, with peak torque delivered at a relatively low RPM. This design gives it exceptional climbing power on steep gradients, while keeping fuel consumption far lower than older, less optimized heavy-duty trucks. Matched with a FAST 12-speed manual transmission, the entire powertrain is built for millions of kilometers of continuous operation, with minimal breakdowns even under 24/7 heavy-load schedules.
The Camion Shacman F3000 4×2 tractor is not just a truck — it is a profit-generating asset for fleet operators. It supports both left-hand drive and right-hand drive customization to fit local traffic rules in different regions. With massive existing fleets in all major target markets, spare parts are widely available at affordable prices, and local mechanics already know how to service it without special training. For small to mid-sized logistics companies, this model delivers far lower long-term operating costs than premium European imported trucks, while still matching their core heavy-duty performance.
| Category | Item | Technical Details |
| Truck Name | Camion Shacman F3000 | |
| Basic Vehicle Info | Official Model | SX4186NN361 |
| Brand | SHACMAN | |
| Series | F3000 | |
| Drive Type | 4×2 | |
| Cab Configuration | Single sleeper, high roof, with factory A/C | |
| Steering Position | Left-hand drive (right-hand drive customizable) | |
| Dimensions & Weights | Overall Length (mm) | 6150 |
| Overall Width (mm) | 2490 | |
| Overall Height (mm) | 3624 | |
| Wheelbase (mm) | 3600 | |
| Curb Weight (kg) | 7500 | |
| Gross Vehicle Weight (kg) | 18000 | |
| Max. Towed Trailer Mass (kg) | 35000 | |
| Fifth Wheel Load Capacity (kg) | 10370 | |
| Powertrain | Engine Brand | WEICHAI |
| Engine Model | WP12.400E201 | |
| Emission Standard | Euro II (higher emission versions available on request) | |
| Displacement (L) | 11.596 | |
| Rated Power | 294kW / 400HP | |
| Fuel Type | Diesel | |
| Transmission & Axles | Transmission Brand | FAST |
| Transmission Model | 12JSD200T-B | |
| Front Axle Brand & Spec | HANDE MAN 7.5T | |
| Rear Axle Brand & Spec | HANDE 13T single reduction | |
| Final Drive Ratio | 4.875 | |
| Performance | Maximum Speed (km/h) | 90 |
| Maximum Gradeability | ≥ 30% | |
| Fuel Tank Capacity (L) | 400 (aluminum alloy optional) | |
| Tires & Chassis | Tire Specification | 12R22.5 radial tire, 6 units total |
| Frame Spec | 850×300mm, high-strength reinforced frame | |
| Market & Delivery | Target Scenarios | Container transport, long-haul logistics, port drayage |
| FOB Reference Price | US $28,000-33,000 / unit | |
| Delivery Lead Time | 30-35 working days | |
| Warranty | 12 months / 100,000 km | |
