Moto Model – SX1040E3D16B3411N2JEN
GVW – ≤ 8T
Power Battery – 100kwh
Front Axle – 2.2T
Rear Axle – 3.5t/16.193
Wheelbase(mm) – 3360
Moto Model – SX1040E3D16B3411N2JEN
GVW – ≤ 8T
Power Battery – 100kwh
Front Axle – 2.2T
Rear Axle – 3.5t/16.193
Wheelbase(mm) – 3360
Zero-Emission EV Powertrain
Powered by a high-capacity CATL Lithium Iron Phosphate (LFP) battery paired with a high-efficiency Fast/Inovance permanent magnet synchronous motor. Delivers quiet operation, smooth acceleration, and zero direct tailpipe emissions to comply with strict urban environmental standards.
Heavy-Duty Chassis & Strong Payload
Built on a reinforced high-strength steel chassis frame and robust axle system, the Zhiyun S100 guarantees exceptional payload capacity and stability on rough job sites and unpaved roads.
Fast DC Charging & Smart Energy Recovery
Supports high-power DC fast charging, allowing the battery to reach 80% charge in under an hour. Coupled with advanced regenerative braking technology, it maximizes driving range and lowers daily operating costs.
Smart & Ergonomic Driver Cabin
Features a modern driver-centric cabin with an LCD instrument display, ergonomic seating, multi-function controls, and clear visibility to ensure driver comfort and safety during long working hours.
Significantly Lower TCO (Total Cost of Ownership): Electric power cuts fuel expenses by up to 60%, while simplifying powertrain maintenance compared to diesel engines.
Urban Area Access: Zero-emission status grants unrestricted access to green zones and night-shift urban construction operations.
Reliable SHACMAN Quality: Engineered with decades of com
| Category | Parameter / Item | Technical Specification |
| Basic Information | Vehicle Model | Shacman I9 Pure Electric Dump Truck(Chassis: SX3120EV321N) |
| Drive Type | 4×2 | |
| Emission Standard | Zero Emission / Pure Electric | |
| Dimensions & Mass | Gross Vehicle Weight (GVW) | 11,995 kg (12-Ton Class) |
| Payload Capacity | Approx. 5,000 – 6,500 kg | |
| Wheelbase | 3,300 mm – 3,750 mm | |
| Cargo Box Dimensions (L×W×H) | Approx. 3,800 × 2,100 × 800 mm (Customizable for muck/sand) | |
| Battery & Range | Battery Brand & Type | CATL Lithium Iron Phosphate (LFP) |
| Battery Capacity | 140.95 kWh | |
| Driving Range | 200 – 260 km (Depending on load and road conditions) | |
| Charging Type | High-Power DC Fast Charging (SOC 20%-80% in ~45 mins) | |
| Motor & Performance | Motor Model & Type | TZ375XSSF-SZF614 Permanent Magnet Synchronous Motor (PMSM) |
| Peak Power / Torque | 185 kW / High-Torque Electric Drive System | |
| Top Speed | 85 – 90 km/h | |
| Chassis & Brake | Front / Rear Axle | Reinforced Front Axle / Hande Heavy-Duty Rear Axle |
| Suspension System | Multi-leaf Springs with Shock Absorbers | |
| Brake System | Air Brakes + ABS + Regenerative Energy Recovery | |
| Tire Size | 245/70R17.5 / 18PR | |
| Tipping System | Hydraulic Lift Mechanism | Middle / Front Underslung Hydraulic Cylinder System |
| Cargo Box Material | High-strength wear-resistant steel with optional electric tarp cover |
